Cebora Mig 344 3 Phase Welder

Description

The Cebora Mig 344 is a dual voltage (220V/480V) 3 phase welder capable of welding from thin sheet metal, to heavy structural welds.

It is set up to accept two mig guns; push-pull gun for aluminum, and a heavy-duty gun for steel or silicon bronze. Software is included for OEM specific wires, and double pulse capability makes it easy to weld aluminum. Welder set up is easy using the LCD display to scroll through the most extensive library of welding programs and choose the right one for the job at hand.

The Mig 344 is supplied already mounted on a cart for easy mobility around the shop.

Accepted Wire Size

• 0.8/0.9/1.0/1.2 Aluminum
• 0.6/0.8/0.9/1.0/1.2 Steel
• 0.8/0.9/1.0/1.2 Stainless Steel
• 0.8/0.9/10. SilBrz
• Max Spool size 300mm / 15Kg 12" / 33lbs.

Benefits

• User-friendly LCD Display
• 4-roller double wire feed unit and over 70 welding programs
• Preset for Pulse and Double Pulse functions
• Software updating in few seconds

Accessories

• Art-2003 Push-Pull torch
• Art-1242 Heavy-duty 280A' MIG torch
• Art-1450 Flow meter with 2 pressure gauges
• Art-1933 Aluminum Kit

Features & Benefits

• Cebora double aluminium 4-roller-wire feed unit ( Ø 30 mm)
• Equipped with power source transportation trolley, ground lead ( 3,5 m – 35 mm2) and clamp
• Wide range of standard synergic curves for Solid, Stainless steel, Aluminium. It’s suitable for welding and brazing galvanized sheet metal, high strength steel and flux-cored alloys. The The microprocessor in the control circuit makes it possible to upgrade, even over a long period, the synergic programs stored in the machine by means of an optional kit (art. 136)
• User-friendly 5" LCD Display
• Pulse upgrade function ,which allows to activate synergic curves dedicated to solid, mild steel, stainless steel, aluminum and CuSi3. It has got more than 75 welding programs
• Double Pulse function
• Two separate 4-roller-wire feed motors, allowing to work with two different types of coils, thus keeping assembled two type of different torches with different wires. (Also CEBORA Push-Pull 2003 torch)
• The power source is supplied with many adjustable functions which can be accessed from the panel, including:
• Arc Length, 2/4 strokes, Spot Time, Pause Time, Inductance, Burn Back, Soft Start etc – SHORT or PULSE process
• Three importants specific functions dedicated to an optimal aluminum welding (3 levels, Automatic Hot Start, Automatic Crater Filler)
• Euro connector allows to use either a MIG standard torch or a Push-Pull 2003 one
• It is possible to work with two different types of coils: Ø 200 mm or Ø 300 mm
